Operating the machine
21
Pos : 9. 8 / 0020 Ü bersc hrift en/ 1. 1 Übersc hrift en/1.1 Übersc hrift en BD A/ 11 Übersichtst abelle der Ger ät et eile @ 0\ mod_1228990616846_9.doc x @ 4972 @ 2 @ 1
5.3 Overview table of the parts of the device
Pos : 9. 9 / 0005 R ETSCH Bedi enungsanlei tungen Kapit elsamml ung en/AS200Jet/ 0007 AS200J et Bedi enung/AS200Jet M odul T abelle der G er äteteil e @ 1\ mod_1239875152197_9. doc x @ 8150 @ @ 1
Element Description Function
A Lid for air jet sieving Lid for the test sieve
B Test sieve Sieve for the dry sieving and/or particle size
determination
C Display Displays the control functions and parameters
D Start button Starts sieving
E Stop button Stops sieving
F Operating knob Dial for changing the device settings
G Quick start button Starts quick sieving
H Air outlet channel Connection for external exhaust
I Air inlet channel Opening for air inlet
J Connection for automatic air flow
regulation Connector socket for external air flow regulation
K Serial PC - Port (RS232) PC connection for data communication with
EasySieve®
L USB interface PC connection for data communication with
EasySieve®
M On/Off switch Disconnects the device from the mains / including
thermal and switchable power fuse
O IEC C14 appliance inlet Mains connection
P IEC C13 connector Power connection for the external vacuum cleaner
R Cover for differential pressure sensor Protects the differential pressure sensor
S Air nozzle Conducts the air jet upwards onto the sieve
T Nozzle compartment Feeds the material to be sieved to the air outlet
channel
