Technical data
13
Fig. 1: Connecting the sound absorber
Put the position pin (IB) into the opening marked in the picture in order to lock the
sound absorber in a horizontal position.
Pos : 5. 13 /0020 Übersc hrift en/1.1 Ü bersc hriften/ 1. 1 Ü berschrif ten BDA/11 M axi mal e Bel ast ung @ 0\ mod_1228983528905_9. doc x @ 4880 @ 2 @ 1
3.3 Maximum Load
Pos : 5. 14 /0005 RET SCH/ 0005 R ETSCH Bedienungsanlei tungen Kapit elsamml ung en/AS200Jet/ 0005 AS200J et Tec hnische D at en/AS200J et M odul Siebgut menge M axi male Siebt ur mmasse @ 1\ mod_1236585803100_9. doc x @ 7826 @ @ 1
NOTICE
Ensure that the differential pressure or vacuum generated by your vacuum cleaner
or the suction is not greater than 100 mbar (9999 Pa).
The maximum quantity of material to be sieved depends on the mesh size and
sieve size.
Pos : 5. 15 /0020 Übersc hrift en/1.1 Ü bersc hriften/ 1. 1 Ü berschrif ten BDA/11 Sc hut zart @ 0\ mod_1226491839164_9. doc x @ 3328 @ 2 @ 1
3.4 Degree of protection
Pos : 5. 16 /0005 RET SCH/ 0005 R ETSCH Bedienungsanlei tungen Kapit elsamml ung en/AS200Jet/ 0005 AS200J et Tec hnische D at en/AS200J et M odul Sc hutzar t @ 1\ mod_1236585802584_9. doc x @ 7810 @ @ 1
– IP40
Pos : 5. 17 /0020 Übersc hrift en/1.1 Ü bersc hriften/ 1. 1 Ü berschrif ten BDA/11 Abmess ungen und G ewic ht R et sch @ 0\ mod_1226492212173_9. doc x @ 3352 @ 2 @ 1
3.5 Dimensions and weight
Pos : 5. 18 /0005 RET SCH/ 0005 R ETSCH Bedienungsanlei tungen Kapit elsamml ung en/AS200Jet/ 0005 AS200J et Tec hnische D at en/AS200J et M odul Abmess ungen und Gewic ht @ 1\ mod_1236585800975_9. doc x @ 7770 @ @ 1
Height : 288 mm (without lid)
Width: 460 mm
Depth: 305 mm
Weight: approx. 14 kg
Pos : 5. 19 /0020 Übersc hrift en/1.1 Ü bersc hriften/ 1. 1 Ü berschrif ten BDA/11 Erfor derlic he Standfläc he @ 0 \ mod_1226492678414_9. doc x @ 3364 @ 2 @ 1
3.6 Required floor space
Pos : 5. 20 /0005 RET SCH/ 0005 R ETSCH Bedienungsanlei tungen Kapit elsamml ung en/AS200Jet/ 0005 AS200J et Tec hnische D at en/AS200J et M odul Erf orderliche Standfl äche @ 1\ mod_1236585801975_9.doc x @ 7794 @ @ 1
460 mm x 320 mm; no safety spacing required
Pos : 5. 21 /0020 Übersc hrift en/1.1 Ü bersc hriften/ 1. 1 Ü berschrif ten BDA/11 N ennl eist ung @ 0\ mod_1226491873164_9.doc x @ 3334 @ 2 @ 1
3.7 Rated power
Pos : 5. 22 /0005 RET SCH/ 0005 R ETSCH Bedienungsanlei tungen Kapit elsamml ung en/AS200Jet/ 0005 AS200J et Tec hnische D at en/AS200J et M odul N ennl eist ung @ 1\ mod_1236585802287_9.doc x @ 7802 @ @ 1
• AS200jet: maximum 50 watts
• AS200jet + HDS200 or GM80 vacuum cleaner: maximum 1450 watts
I
IS
IB
