MacDon 5010 Mower Conditioner - Manual (Page 69)

67
OPTIONS & ATTACHMENTS
The following attachments and optional equipment are available from your Dealer:
ADDITIONAL SKID PLATES WholeGoods order number: B2149
In addition to the standard two outer skid plates, two inner plates may be added for extra control of cutting
height and protection of cutting components. See "Cutting Height" in Operation section.
PTO CONVERSION KITS Parts order number:
540 rpm PTO pump kit – 36909
1000 rpm PTO pump kit – 36859
Kits are for converting from 540 to 1000 RPM or
vice-versa.
CROP DIVIDERS
WholeGoods order number: B2539
Crop dividers mount to lean bar for clean crop
dividing and reel entry in tall crops. Left and right
dividers are included in the kit.
The amount of crop "gathered" by the divider is
adjustable. For the most aggressive gathering,
mount the divider at the two forward holes (A) and
position the U-bolt (B) farther inboard on the lean
bar.
For the least aggressive gathering, mount the
divider at the two rearward holes (C) and position
the U-bolt (B) farther outboard on the lean bar.
Use minor adjustments of U-bolt position to
achieve best results in specific conditions.
Crop dividers should be removed for flat-bed
transport or for storage.
STUB GUARD CONVERSION KIT
WholeGoods order number:
12’ – B2515
14’ – B2516
16’ – B2517
Stub guards, complete with top guides and
adjuster plates are designed to cut tough crops.
Installation and adjustment instructions are
included with the kit.
STUB GUARDS
CROP DIVIDERS
A
B
MOST AGGRESSIVE
B
C LEAST AGGRESSIVE
