9
SPECIFICATIONS
DIMENSIONS 12 FT. 14 FT. 16 FT.
Overall Width:
Transport Position 13.5 ft. (4103 mm) 15.5 ft. (4713 mm) 17.5 ft. (5323 mm)
Field Position 18.1 ft. (5531 mm) 21.1 ft. (6446 mm) 24.1 ft. (7360 mm)
Overall Length:
Transport Position 20.7 ft. (6320 mm) 22.1 ft. (6740 mm) 24.9 ft. (7573 mm)
Field Position 15.8 ft. (4816 mm) 16.3 ft. (4975 mm) 18.2 ft. (5557 mm)
Overall Height
Transport Position 6.2 ft. (1896 mm)
Field Position 6.2 ft. (1896 mm)
Weight 5400 lbs. (2450 kg) 5800 lbs. (2630 kg) 6200 lbs. (2812 kg)
CUTTERBAR
Cutterbar Width 12.25 ft. (3734 mm) 14.25 ft. (4343 mm) 16.25 ft. (4953 mm)
Cutting Height (on skids) 1.5 to 4 in. (38 to 100 mm)
at 8° guard angle
Guard Angle (adjustable) 6° to 11.5° below horizontal
Cutterbar Range 2.0 in. below ground to 21 in. above ground
at 8° guard angle (to guard tip) (-50 mm to +533 mm)
MAIN DRIVE 540 or 1000 RPM PTO tractor driven pump
to hydraulic motor driving primary shaft
SICKLE
Drive Type Belt driven wobble box (enclosed oil bath)
Speed 1450 strokes or 725 cycles per minute
Stroke 3 in. (76 mm)
Sections Over-serrated, low shoulder
Guards Double heat treated, forged steel
REEL
Drive Type V-belt drive from R/H auger shaft
to chain final drive
Reel Type 5 bats (4 or 6 bats optional),
replaceable steel pick-up tines,
cam action, polymer tine tube bearings
Radius 22 in. (1560 mm) to finger tip
Speed 66 RPM as assembled / 53 RPM with
pulley exchange / 60 RPM optional
NOTE: Specifications listed only under 14 ft. column are common to all sizes.
