10
SPECIFICATIONS
AUGER 12 FT. 14 FT. 16 FT.
Drive Type Chain final drive
Overload Protection Hydraulic motor
Auger Type 20 in. (508 mm) diameter
variable pitch, center feed
Auger Speed 230 RPM
CONDITIONER ROLLS
Drive Type Drivelines from enclosed oil bath chain drive
Roll Type Helical intermeshing steel bars
Roll Diameter 10 in. (254 mm)
Roll Length 93 in. (2360 mm)
Roll Speed 750 RPM
WHEELS
Tread Width 119 in. (3030 mm) 143 in. (3640 mm) 167 in. (4250 mm)
Tires 31 x 13.5 - 15 NHS 8 ply Terra-Rib
Tire Pressure 30 psi (207 kPa)
MATERIAL DISCHARGE
Minimum Width 30 in. (760 mm)
Maximum Width 92 in. (2346 mm)
Rear Fluffing Shield Adjustable
OPERATING SPEED
Recommended Field Speed 5 mph (8 km/h)
Recommended Transport Speed 20 mph (30 km/h)
TRACTOR REQUIREMENTS
Minimum Power 60 hp (45 kw) 75 hp (56 kw) 90 hp (68 kw)
PTO 540 or 1000 RPM - ASAE standard location
Hydraulic Capacity 1750 psi (12000 kPa), two hydraulic circuits
(SPECIFICATIONS AND DESIGN ARE SUBJECT TO CHANGE WITHOUT NOTICE OR OBLIGATION TO
REVISE UNITS PREVIOUSLY SOLD.)
