44

MAINTENANCE/SERVICE

GREASING THE WINDROWER (continued)

100 Hours:

1. Wheel Hub Bearings (D) - two fittings

CENTER LINK BALL JOINTS

Apply SAE 30 or equivalent lightweight oil to the

center link ball joints (A) every 50 hours.

SPRING PIVOTS

Apply SAE 30 or equivalent lightweight oil to the

spring pivots (B) every 50 hours.

HITCH PIN LOCK NUT

Check hitch pin nut (C) every 50 hours. Maintain

350 ft. lbs. (475 N

⋅m) torque.

WHEEL HUB BEARINGS

D

OIL SPRING PIVOTS

B

CHECK HITCH PIN LOCK NUT

C

A

OIL CENTER LINK BALL JOINTS
