49
Adapter Mounting Instructions
for Gleaner Combines
PREPARING THE ADAPTER (continued)
5. Place feed auger in rearward position.
To adjust:
a. Loosen bolt (E), both sides.
b. Remove bolt (F), both sides, and swing auger
to desired position.
c. Replace and tighten hardware.
PREPARING THE COMBINE
1. For R62 combines, check with Combine dealer to ensure combine is equipped with tire size, rear ballast
etc. to carry larger headers.
2. Rotate feeder house latches back into the feeder house.
3. Set feeder house face plate to mid-position.
FEED AUGER FULLY REARWARD
F
E
