2
CAUTION: This information is subject to change without prior notice.
Copyright 2014, Opticon Sensors Europe BV, all rights reserved.
This manual may not, in whole or in part, be copied, photocopied, reproduced, translated or converted to any
electronic or machine readable form without prior written consent of Opticon Sensors Europe.
THE GENERAL USE AND FUNCTIONING OF THE BAR CODE SCANNER IS DESCRIBED IN THIS DOCUMENT.
ALSO GENERAL SETUP INSTRUCTIONS TO GET STARTED ARE DESCRIBED IN THIS DOCUMENT. FOR
FURTHER INSTRUCTIONS CONSULT OPTICON OR YOUR LOCAL DEALER.
Overview
The OPN2005/6 and PX20 barcode terminals are, by default, supplied with this Bluetooth
demo application that demonstrates
the devices’ Bluetooth capabilities. Since both terminals
don ’t have a display to show instructions nor have a keyboard to change the settings, a user
interface is implemented that consists entirely of using just the two keys and reading
barcodes. This brief setup guide describes the features as well as instructions to be able to
use this demo application.
More product details, additional support or configuration options to your own preferences (by
Universal menu book) will be updated at
www.opticon.com
Information about how to install and use a Bluetooth stack on your remote device, like a PC or
mobile device, please check the manual of your Bluetooth device.
Capabilities
The following features are currently supported:
 Connecting to a remote host device (as master) and transmitting data using a Bluetooth
virtual COM port (VCP)
 Making the barcode scanner connectable and discoverable (as slave) to allow a remote
host device to connect with the barcode scanner, enabling the transmission of data using
a Bluetooth virtual COM port (VCP)
 Making the barcode scanner connectable and discoverable (as slave) as an HID
(keyboard) device to allow the remote host device to connect, whereupon it transmit each
character of barcode data as keyboard presses
 Reconnecting to a paired remote host device (as master) to quickly reestablish a lost
Bluetooth HID connection without having to redo the pairing.
 Secure Simple Pairing, which allows the OPN2005/6 and PX20 to pair with a remote host
device without the user having to enter a PIN code
 Opticon Universal menu book support to configure barcode decoders, prefixes and
suffixes, read modes, buzzer/LED settings, Bluetooth configurations, and switching
between HID or VCP as the Bluetooth interface
 Use of the trigger and clear key to quickly (re)connect, disconnect and make discoverable
 Storing of settings in non-volatile memory to allow all settings to be restored after a reset
 Configuration of the application by using Opticon serial commands
 Easy software upgrading by USB-VCP using Appload.
 iPhone / iPad compatibility
 USB-VCP and USB-HID support when not connected to Bluetooth
 Low battery warning and battery check
