GRAPHICAL DEMO APPLICATION - PAGE 18
4. Battery
4.1. Battery charging
If the OPL9724 with the battery pack is placed
in the cradle, the voltage and the required
loading time is automatically determined.
During charging the OPL9724 shows one of
the images on the left. Also the RED led on
the terminal will emit.
When the battery is fully charged the led will
be GREEN and the image on the left will be
shown. The voltage meter shows the voltage
on the contacts of the battery.
Note
• When sending data (transmission) battery will also be charged. The led will emit RED or
GREEN, but the charging image is not displayed.
