Barco R9002327 User Manual
Page 47
INSTALLATION ADJUSTMENTS
INSTALLATION ADJUSTMENTS
7-14
INSTALLATION
ADJUSTMENTS
7-14
INSTALLATION
ADJUSTMENTS
5975069A BARCOVISION 708 200498
5975069A BARCOVISION 708 200498
CRT projection angle adjustment
The projection angle of the red and blue CRT's is dependent on the desired size of
the projected image. If the centers of green, blue and red do not coincide, the CRT
projection angle must be adjusted. Never try to correct this misalignment with the shift
correction or the static convergence controls. These controls may only be applied
to correct small errors which cannot be corrected by the CRT angle adjustment.
Ensure that the rasters are centered on
the CRT face.
Press ENTER to start the CRT angle
adjustment procedure. A crosshairs
(green and red) will be displayed on the
screen.
ENTER continues with the second part
EXIT returns to raster shift adjustment
ADJUST returns to operational mode.
Loosen the four hexagon screws A, A',
B and B', upper and lower fixation latch.
of the CRT projection angle adjustment.
EXIT returns to Raster shift adjustment.
ENTER continues to the crosshairs align-
ment.
CRT PROJECTION ANGLE
ADJUSTMENT
CRT PROJECTION ANGLE IS
THE FIRST STEP OF STATIC
CONVERGENCE ADJUSTMENT.
IT IS CRITICAL THAT THE
RASTERS ARE CENTERED ON
THE CRT FACE PLATES
PRIOR TO PERFORMING
THIS STEP.
...
CRT PROJECTION ANGLE
ADJUSTMENT
DURING THIS PROCEDURE,
RED ON GREEN AND THEN
BLUE ON GREEN CROSSHAIRS
WILL BE DISPLAYED
TO ALLOW THE RED AND
BLUE CRTS TO BE ALIGNED
WITH THE GREEN CRT.
LOOSEN BOLTS A AND B
TO PIVOT THE RED CRT,
AND BOLDS C AND D
TO PIVOT THE BLUE CRT.
CRT projection angle adjustment
The projection angle of the red and blue CRT's is dependent on the desired size of
the projected image. If the centers of green, blue and red do not coincide, the CRT
projection angle must be adjusted. Never try to correct this misalignment with the shift
correction or the static convergence controls. These controls may only be applied
to correct small errors which cannot be corrected by the CRT angle adjustment.
Ensure that the rasters are centered on
the CRT face.
Press ENTER to start the CRT angle
adjustment procedure. A crosshairs
(green and red) will be displayed on the
screen.
ENTER continues with the second part
EXIT returns to raster shift adjustment
ADJUST returns to operational mode.
Loosen the four hexagon screws A, A',
B and B', upper and lower fixation latch.
of the CRT projection angle adjustment.
EXIT returns to Raster shift adjustment.
ENTER continues to the crosshairs align-
ment.
CRT PROJECTION ANGLE
ADJUSTMENT
CRT PROJECTION ANGLE IS
THE FIRST STEP OF STATIC
CONVERGENCE ADJUSTMENT.
IT IS CRITICAL THAT THE
RASTERS ARE CENTERED ON
THE CRT FACE PLATES
PRIOR TO PERFORMING
THIS STEP.
...
CRT PROJECTION ANGLE
ADJUSTMENT
DURING THIS PROCEDURE,
RED ON GREEN AND THEN
BLUE ON GREEN CROSSHAIRS
WILL BE DISPLAYED
TO ALLOW THE RED AND
BLUE CRTS TO BE ALIGNED
WITH THE GREEN CRT.
LOOSEN BOLTS A AND B
TO PIVOT THE RED CRT,
AND BOLDS C AND D
TO PIVOT THE BLUE CRT.
