INSTALLATION SET UP INSTALLATION SET UP
4-7
INSTALLATION
SET
UP
4-7
INSTALLATION
SET
UP
5975069A BARCOVISION 708 200498 5975069A BARCOVISION 708 200498
After scan inversion, close the chassis and close the top cover. Reconnect the
power cord to the wall outlet.
Note
Switching over from floor to ceiling or vice versa requires a complete readjustment
of picture geometry and convergence.
Check of the correct connector position
Note : this check procedure can only be done after power (mains) connection. So,
first continue with the projector set up and the connections and then return to this
checking procedure.
Switch on the BARCOVISION 708 MULTIMEDIA and press ADJUST to start up the
adjustment mode. Select with the control disc 'Service' and press ENTER. The
service menu will be displayed. Select 'PROJECTOR SET UP' and press ENTER. Select
'IDENTIFICATION' and press ENTER. On this screen, information is given about the
projectors configuration.
Configuration when leaving the factory : ceiling/front configuration.
Follow next procedure to check the configuration :
- switch on the projector.
- the projector starts up on the last
selected source.
- press the ADJUST key.
- highlight 'service' with the control
disc and press ENTER.
The 'service mode menu' will be dis-
played
- select with the control disc 'Projector
set up' and press ENTER.
Select with or
then
to return.
SERVICE MODE
PROJECTOR SETUP
MEMORY MANAGEMENT
COMMON SETTINGS
I²C DIAGNOSTICS
After scan inversion, close the chassis and close the top cover. Reconnect the
power cord to the wall outlet.
Note
Switching over from floor to ceiling or vice versa requires a complete readjustment
of picture geometry and convergence.
Check of the correct connector position
Note : this check procedure can only be done after power (mains) connection. So,
first continue with the projector set up and the connections and then return to this
checking procedure.
Switch on the BARCOVISION 708 MULTIMEDIA and press ADJUST to start up the
adjustment mode. Select with the control disc 'Service' and press ENTER. The
service menu will be displayed. Select 'PROJECTOR SET UP' and press ENTER. Select
'IDENTIFICATION' and press ENTER. On this screen, information is given about the
projectors configuration.
Configuration when leaving the factory : ceiling/front configuration.
Follow next procedure to check the configuration :
- switch on the projector.
- the projector starts up on the last
selected source.
- press the ADJUST key.
- highlight 'service' with the control
disc and press ENTER.
The 'service mode menu' will be dis-
played
- select with the control disc 'Projector
set up' and press ENTER.
Select with or
then
to return.
SERVICE MODE
PROJECTOR SETUP
MEMORY MANAGEMENT
COMMON SETTINGS
I²C DIAGNOSTICS
Select with or
then
to return.
ADJUSTMENT MODE
Select a path from below :
GUIDED
RANDOM ACCESS
INSTALLATION
SERVICE
IRIS
Source 1
Select with or
then
to return.
ADJUSTMENT MODE
Select a path from below :
GUIDED
RANDOM ACCESS
INSTALLATION
SERVICE
IRIS
Source 1
