Barco R9002327 User Manual
Page 44
INSTALLATION ADJUSTMENTS
INSTALLATION
ADJUSTMENTS
INSTALLATION ADJUSTMENTS
INSTALLATION
ADJUSTMENTS
7-11
7-11
5975069A BARCOVISION 708 200498
5975069A BARCOVISION 708 200498
Electrical focusing
The electrical focus for red, green and blue is factory preset. When they have to
be readjusted, follow the procedure as described below :
- Ensure the lenses are correctly focused.
- Open the top cover.
- Adjust separately the focus control for red, green and blue for the sharpest image
on the screen.
Electrical focusing
The electrical focus for red, green and blue is factory preset. When they have to
be readjusted, follow the procedure as described below :
- Ensure the lenses are correctly focused.
- Open the top cover.
- Adjust separately the focus control for red, green and blue for the sharpest image
on the screen.
Electrical focus
Red Green Blue
Electrical focus
Red Green Blue
