Push the control disc up or down to
highlight "Installation" and press EN-
TER.
ENTER continues displaying a WARN-
ING.
EXIT returns to operational mode.
ADJUST returns to operational mode.
A warning will be displayed on the
screen.
If you are qualified installation or serv-
ice personnel, press ENTER to start up
the installation mode.
When entering the installation mode,
the projector will automatically switch
to the internal pattern on 15 kHz/50 Hz.
ENTER asks for your password.
EXIT returns to the path selection menu.
Select with or
then
to return.
ADJUSTMENT MODE
Select a path from below :
GUIDED
RANDOM ACCESS
INSTALLATION
SERVICE
IRIS
Source 1
