MAYCO MG-30 PUMP — OPERATION AND PARTS MANUAL — REV. #3 (09/15/11) — PAGE 99
MG-30 PUMP — MANIFOLD (3-INCH OUTLET) ASSY.
MANIFOLD (3-INCH OUTLET) ASSY.
NO. PART NO. PART NAME QTY. REMARKS
2 EM402385 CONNECTING MANIFOLD 1
3 EM402774 PUMP MANIFOLD 3-INCH 45 OUTLET ....... 1 .......... (TAG UNIT)
3 EM402775 PUMP MANIFOLD 3 -INCH STR. OUTLET .. 1 .......... (MOBIL UNIT)
6 EM402388 HOPPER ELBOW 1
8 EM403000 MATERIAL CYLINDER 3.75" DIA ................ 2 .......... HIGH VOLUME
12 EM402977 STUD - 1 X 5-1/2 IN 3
14 EM503111 CAP SCREW 1/2 X 4 - 1/2 IN 1
16 EM402473 SLEEVE FOR FIREPROOF KIT 1
18 EM492584 HEX NUT 1/2 IN 1
20 EM968002 HEX NUT 3/4 IN 2
22 EM619 WASHER 3/4 IN 6
24 EM510849 STUD - 3/4 X 3 IN 2
26 EM402581 QUARTER ROUND SEAL 2
28 EM402418 CONNECTING RING 1
32 EM402579 STEEL BALL 2
34 EM402995 VALVE SEAT WITHOUT PIN 2
36 EM402580 SPECIAL O-RING 3
38 EM512914 WASHER - 1 IN 2
40 EM968020 HEX NUT - 1 IN 2
42 EM512612 HEX NUT - 1 IN 1
44 EM914312 SEAL 1
48 EM492399 CAP SCREW - 1/2 X 3 IN 1
50 EM402415 SLEEVE SHORT 1
52 EM492584 HEX NUT - 1/2 IN 1
54 EM402986 SQUARE WASHER - 1 IN 1
58 EM968002 HEX NUT - 3/4 IN 1
60 EM505988 PIPE PLUG - 1 IN 1
62 EM966207 “T” SLOT BOLT - 1/2 IN X 2 - 1/4 IN 2
66 6109160 HEX NUT - 1/2 IN 2
This parts list is intended to be used with
ONLY the MG30M-3 and MG30T-3 Models,
using Fireproofing materials. This
application uses a 3.0-inch (76.2 mm)
outlet.
NOTE
