PAGE 34 — MAYCO MG-30 PUMP — OPERATION AND PARTS MANUAL — REV. #3 (09/15/11)
2.
Determine if the mixer engine oil is low (Figure 17), add
correct amount of engine oil to bring oil level to a normal
safe level. See Table 7 for recommended oil type.
ZERK GREASE FITTINGS
1.
Check the zerk grease fittings at each end of the mixing
drum (Figure 18). These grease fittings lubricate the
dumping mechanism. If the dumping handle is stiff or hard
to move lubricate these fittings.
Figure 17. Dipstick (Mixer Engine)
Figure 18. Zerk Fittings (Bearings)
MG-30 PUMP — PRE-INSPECTION (MIXER)
LUBRICANTS
CLUTCH OIL
1.
Remove the clutch oil level plug (Figure 19). If oil begins
to seep out as the plug is being removed, then it can be
assumed that the clutch oil is at the proper operating level.
2.
If oil does not seep out as the oil level plug is being removed,
then remove the clutch oil fill plug and fill with SAE 30
engine oil to the proper operating level.
GEAR REDUCTION OIL (TRANSMISSION)
1.
Remove the transmission oil level plug (Figure 19). If
oil begins to seep out as the plug is being removed, then it
can be assumed that the transmission oil is at the proper
operating level.
2.
If oil does not seep out as the oil level plug is being removed,
then remove the transmission oil fill plug and fill with
SAE 90 transmission oil to the proper operating level.
Figure 19. Transmission/Clutch Lubrication
e
d
a
r
G
li
O
r
o
t
o
M
.
7
e
l
b
a
T
n
o
s
a
e
S
e
r
u
t
a
r
e
p
m
e
T
li
O
r
o
t
o
M
f
o
e
d
a
r
G
)
s
s
a
l
c
S
M
n
a
h
t
r
e
h
g
i
h
(
r
e
m
m
u
S
r
e
h
g
i
H
r
o
)
F
°
7
7
(
C
°
5
2
0
3
-
W
0
1
E
A
S
ll
a
F
g
n
i
r
p
S
)
F
°
0
5
(
C
°
0
1
~
)
F
°
7
7
(
C
°
5
2
0
2
/
0
3
-
W
0
1
E
A
S
r
e
t
n
i
W
)
F
°
2
3
(
C
°
0
r
e
w
o
L
r
O
0
1
-
W
0
1
E
A
S
W
5
E
A
S
