Stile, Flashing profiles accessories slope change detail – Metal Sales Stile Installation User Manual
Page 50
STILE
49
© Metal Sales Manufacturing Corporation/ Subject to change without notice
FLASHING PROFILES
ACCESSORIES
SLOPE CHANGE DETAIL
PITCH BREAK
STILE C-CLOSURE
STILE C-CLOSURE
WOODSCREW XL
STILE CLOSURE
POP RIVET
TUBE SEALANT
PITCH BREAK
WOODSCREW XL
STILE CLOSURE
FASTENER
TUBE SEALANT
STILE PANEL
STILE CLOSURE
TUBE SEALANT
POP RIVETS
(1'-0" O.C. TYPICAL)
WOODSCREW XL
(1'-0" O.C. TYPICAL)
MOISTURE BARRIER
