STILE

9

© Metal Sales Manufacturing Corporation/ Subject to change without notice

VALLEY

EAVE

EXTENDED EAVE

JUNCTION SHEET

DOWNSPOUT

95

O

ELBOW

BOX GUTTER

BOX GUTTER END

FLASHING PROFILES

(CONT)

DOWNSPOUT BRACKET

UNIVERSAL GUTTER/

DOWNSPOUT STRAP

LENGTH 10'-2"

26 GA. PAINTED

LENGTH 10'-2"

26 GA. PAINTED

LENGTH 10'-2"

26 GA. PAINTED

LENGTH 10'-2"

26 GA. PAINTED

LENGTH 1'-4"

26 GA. PAINTED

LENGTH 10'-2"

26 GA. PAINTED

26 GA. PAINTED

26 GA. PAINTED

LENGTH 1'-11"

26 GA. PAINTED

26 GA. PAINTED

4"
