Metal Sales Stile Installation - Manual (Page 23)

STILE
22
© Metal Sales Manufacturing Corporation/ Subject to change without notice
1. In applications where a hip or high side parapet is involved, a Stile C-Closure is used at the
termination of the panel. When Formed Ridge flashing is used Stile C-Closure flashing is not
required.
2. Install the Stile C-Closure along the length of the hip or parapet 2" below the highest point (for
hip condition a Stile C-Closure is required on both sides of the hip).
3. If two or more Stile C-Closures are required, lap the flashing over the previously installed flashing
by a minimum of 3" placing a bead of Tube Sealant between the flashings along the edge where
they lap. Attach Stile C-Closure to the roof deck with Woodscrew XL fasteners placed 12" o.c.
INSTALLATION OF STILE C-CLOSURE
C-CLOSURE
C-CLOSURE
WOODSCREW XL
C-CLOSURE
C-CLOSURE
WOODSCREW XL
2"
2"
