DESIGN / INSTALLATION CONSIDERATIONS
(CONT)
1:12
2:12
3:12
4:12
5:12
6:12 1.0035
1.0138
1.0308
1.0541
1.0833
1.1180 1.4167
1.4240
1.4362
1.4530
1.4743
1.5000 7:12
8:12
9:12
10:12
11:12
12:12
1.1577
1.2019
1.2500
1.3017
1.3566
1.4142 1.5298
1.5635
1.6008
1.6415
1.6853
1.7320
ROOF SLOPE FACTOR CHART
SLOPE HIP/VALLEY
SLOPE FACTOR MULTIPLIER
SLOPE HIP/VALLEY
SLOPE FACTOR MULTIPLIER
S
L
(L) X (SLOPE FACTOR) = S
EAVE
PEAK
(L) X (HIP VALLEY MULTIPLIER) = H
HIP OR VALLEY
L
H
EXAMPLE:
RIDGE
EAVE OR GUTTER
RAKE
SLOPE
Your Building is 28'-0' wide with a 3:12 pitch.
To determine the panel lengths for each side:
(L) X (SLOPE FACTOR) = S
14'-0" x 1.0308(from chart above for 3:12 slope) = 14.4312
'
OR 14
'
-5"
This chart should be used when specifying and ordering Panels and Flashings. It will help you determine
overall required length of material on sloped applications.
