VENTILATION
Proper design and installation of vapor barriers and ventilation systems are important to prevent
condensation and the resulting problems of moisture damage and loss of insulation efficiency.
On buildings that have an attic space, vents should be placed at both the eave and peak of the roof in
order to prevent a buildup of moisture (humidity) in the attic space.
VENT AT EAVE
VENT
ATTIC INSULATION
BUILDING WITH ATTIC
113 o
133 o
123 o
56 o
123 o
123 o
FLASHING ANGLE SPECIFIER CHART
This chart should be used to determine the required specified angle when considering the following
Stile flashings.
1:12 2:12 3:12 4:12 5:12 6:12 7:12 8:12 9:12 10:12 11:12 12:12
170 o
173 o
94 o
87 o
94 o
94 o
RIDGE
VALLEY
PITCH BREAK
PEAK
EAVE
GUTTER
FLASHING PROFILE
161 o
166 o
99 o
81 o
99 o
99 o
152 o
160 o
104 o
76 o
104 o
104 o
143 o
154 o
108 o
71 o
108 o
108 o
135 o
148 o
112 o
67 o
112 o
112 o
127 o
143 o
116 o
63 o
116 o
116 o
120 o
138 o
120 o
60 o
120 o
120 o
106 o
129 o
126 o
53 o
126 o
126 o
100 o
126 o
128 o
50 o
128 o
128 o
95 o
123 o
132 o
47 o
132 o
132 o
90 o
120 o
135 o
45 o
135 o
135 o
DESIGN / INSTALLATION CONSIDERATIONS
(CONT)
