67
Maintenance and Servicing
5. Unlock the plastic fixing of the tubes that need to be replaced on both sides and pull out
the tubes carefully ( Fig. 38 ).
1
1
2
2
Fig. 38
1 Remove the plastic fixing and slide to the middle.
Fig. 38 Fig. 38
2 Pull the tubes carefully out of the holder.
Remove the plastic fixing and slide to the middle. Remove the plastic fixing and slide to the middle.
6. Insert new tubes and screw tight.
7. Attach the glass cover and fix it with the restraining plate. To do so, screw in the two Allen
screws on the side again.
8. Put the illumination box back into the cooled incubator.
9. Put in the plug and lock the bayonet catch by turning it right.
10. Check the function of the lighting.
