37
Operation and Control
loop
t3
t4 t2
t1
on
off
Mo Tu We Th Fr Sa Su
3
4
2
1 MIN
AUTO
MAX
°C h
PRINT SETUP
STERI DEFRO
°C
8. Fan speed of first ramp segment Fan speed of first ramp segment
Adjustment range: 10 % to 100 % in 10-% steps In the example shown: fan speed 60 % (six
bars lit up)
loop
t3
t4 t2
t1
on
off
Mo Tu We Th Fr Sa Su
3
4
2
1 MIN
AUTO
MAX
°C h
PRINT SETUP
mb
% rh
STERI DEFRO
°C
9. Setpoint humidity (humidity to end of ramp segment) Setpoint humidity (humidity to end of ramp segment)
Adjustment range: 10 to 80 % rh and OFF. In the example shown: humidity 80.0 % rh.
loop
t3
t4 t2
t1
on
off
Mo Tu We Th Fr Sa Su
3
4
2
1 MIN
AUTO
MAX
°C h
PRINT SETUP
mb
% rh
STERI DEFRO
°C
CO
2
10. CO
2
content of first ramp segment content of first ramp segment
(only for models with CO
2
supply)
Adjustment range: 0 to 20 %. In the example shown: CO
2
content 5.0 %.
loop
t3
t4 t2
t1
on
off
Mo Tu We Th Fr Sa Su
3
4
2
1 MIN
AUTO
MAX
°C h
PRINT SETUP
mb
% rh
STERI DEFRO
°C CO 2
11. UV lighting of the first ramp segment UV lighting of the first ramp segment
(only for models with interior lighting for daylight and UV light)
Adjustment range: on, off
