9400 Technology applications | Synchronism with mark synchronisation
Parameter setting & configuration
Parameterisable function blocks
78
L
EDS94TA10040xxxx EN 1.1 - 10/2008
C03570/1 0.010 s 130.000 Ramp for manual jog
• Initialisation: 1.000 s
C03570/2 0.010 s 130.000 Ramp for continuous operation/
single cycle
• Initialisation: 1.000 s
C03570/3 0.010 s 130.000 Stop ramp
• Initialisation: 1.000 s
C03571/1 String of digits Position unit
• Read only
C03571/2 String of digits Speed unit
• Read only
C03572 -214748.3647 unit/t 214748.3647 Reference speed
• Read only
• Reference value for selecting
speeds.
C03579 -2147483647 2147483647 Status
• Display of the bit-coded output
signal dnState.
C03580 Master position in the target
• Same as output bInTarget
• Read only
0 No
1 Yes
C03581 -214748.3647 unit 214748.3647 Cycle
• Read only
C03582 -214748.3647 unit 214748.3647 Master position at the output
• Display of the dnPosOut_p output
signal in the real unit of the
machine.
C03583 -214748.3647 unit 214748.3647 External master position at the input
• Display of input signal
dnExtMaster_p in real unit of the
machine.
Parameter Possible settings Information
