9400 Technology applications | Synchronism with mark synchronisation
Parameter setting & configuration
Signal configuration
52
L
EDS94TA10040xxxx EN 1.1 - 10/2008
Output port "LPortStatus1"
The output port LPortStatus1 is intended for the connection with a higher-level control.
Output port "LPortStatus2"
The output port LPortStatus2 is intended for the connection with a higher-level control.
Signal (Lenze setting) Output port Signal configuration
Status word 1
Drive ready Status word 1 bit 00 C03121/1
FALSE Status word 1 bit 01 C03121/2
Drive is ready to start Status word 1 bit 02 C03121/3
Error is active Status word 1 bit 03 C03121/4
FALSE Status word 1 bit 04 C03121/5
Normal stop is active Status word 1 bit 05 C03121/6
Switch-on inhibit is active Status word 1 bit 06 C03121/7
Warning is active Status word 1 bit 07 C03121/8
FALSE Status word 1 bit 08 C03121/9
FALSE Status word 1 bit 09 C03121/10
FALSE Status word 1 bit 10 C03121/11
Drive in the limitation Status word 1 bit 11 C03121/12
Homing complete Status word 1 bit 12 C03121/13
Home position available Status word 1 bit 13 C03121/14
FALSE Status word 1 bit 14 C03121/15
FALSE Status word 1 bit 15 C03121/16
Signal (Lenze setting) Output port Signal configuration
Status word 2
FALSE Status word 2 bit 00 C03122/1
FALSE Status word 2 bit 01 C03122/2
FALSE Status word 2 bit 02 C03122/3
FALSE Status word 2 bit 03 C03122/4
FALSE Status word 2 bit 04 C03122/5
FALSE Status word 2 bit 05 C03122/6
FALSE Status word 2 bit 06 C03122/7
FALSE Status word 2 bit 07 C03122/8
FALSE Status word 2 bit 08 C03122/9
FALSE Status word 2 bit 09 C03122/10
FALSE Status word 2 bit 10 C03122/11
FALSE Status word 2 bit 11 C03122/12
FALSE Status word 2 bit 12 C03122/13
FALSE Status word 2 bit 13 C03122/14
FALSE Status word 2 bit 14 C03122/15
FALSE Status word 2 bit 15 C03122/16
