9400 Technology applications | Synchronism with mark synchronisation
Parameter setting & configuration
Parameterisable function blocks
62
L
EDS94TA10040xxxx EN 1.1 - 10/2008
4.14.13 HystTPDiffShaft
4.14.14 HystTPDiffTool
Is an instance of Function
L_SdSetPosition Mark synchronisation (master value):
Conversion of the TP hysteresis selected in the real units of the machine via C03656
into a position in [increments].
Mark synchronisation (master value) (C 34)
Parameter Possible settings Information
C03656 -214000.0000 unit 214000.0000 Position value
• Initialisation: 0.0000 unit
C03657 String of digits Position unit
• Read only
C03658 -2147483647 2147483647 Status
• Read only
Is an instance of Function
L_SdSetPosition Mark synchronisation (setpoint):
Conversion of the TP hysteresis selected in the real units of the machine via C03876
into a position in [increments].
Mark synchronisation (setpoint) (C 39)
Parameter Possible settings Information
C03876 -214000.0000 unit 214000.0000 Position value
• Initialisation: 0.0000 unit
C03877 String of digits Position unit
• Read only
C03879 -2147483647 2147483647 Status
• Read only
