9400 Technology applications | Synchronism with mark synchronisation
Parameter setting & configuration
Parameterisable function blocks
58
L
EDS94TA10040xxxx EN 1.1 - 10/2008
4.14.7 DisplayClutchSpeed
C03721 -214748.3647 unit/t 214748.3647 Speed X at the output
• Read only
• Is generated from the speed
signal dnXSpeedOut_s.
C03722 -214748.3647 unit/t 214748.3647 Speed Y at the output
• Read only
• Is generated from the speed
signal dnYSpeedOut_s.
C03723 -214748.3647 unit 214748.3647 Position X at the output
• Display of output signal
dnXActPos_p in real unit of the
machine.
C03724 -214748.3647 214748.3647 Status
• Display of the bit-coded output
signal dnState.
Parameter Possible settings Information
Is an instance of Function
L_LdExtrapolate Extrapolation of current master shaft position in the register for speed display.
Parameter Possible settings Information
C03705 1 127 Number of extrapolation cycles
• Initialisation: 1
C03706/1 String of digits Position unit
• Read only
C03706/2 String of digits Speed unit
• Read only
C03712 -214748.3647 unit/t 214748.3647 Speed at the output
• Read only
• Is generated from the speed
signal dnSpeedOut_s.
C03713 -214748.3647 unit 214748.3647 Position at the output
• Display of the dnPosOut_p output
signal in the real unit of the
machine.
C03714 Extrapolation cycles > selected value
• Read only
0 No (OK)
1 Yes (error)
