9400 Technology applications | Positioning sequence control
Parameter setting & configuration
Parameterisable function blocks
74
L
EDS94TA10060xxxx EN 1.2 - 03/2010
5.14.12 MonitFollowError1
5.14.13 MonitFollowError2
C03915 String of digits Position unit
• Read only
C03916 -2147483647 2147483647 State
• Read only
Parameter Possible settings Information
Is an instance of Function
L_LdMonitFollowError Following error monitoring ( 54)
Parameter Possible settings Information
C03960 -214748.3647 unit 214748.3647 Following error at the input
• Display of the input signal
dnFollowErrorIn_p in the real unit
of the machine.
C03961 String of digits Position unit
• Read only
C03963 Following error out of tolerance
• Read only
FALSE Following error smaller than set
switching threshold
TRUE Following error larger than set
switching threshold
C03964 Following error monitoring activated
• Read only
FALSE Deactivated
TRUE Activated
Is an instance of Function
L_LdMonitFollowError Following error monitoring ( 54)
Parameter Possible settings Information
C03965 -214748.3647 unit 214748.3647 Following error at the input
• Display of the input signal
dnFollowErrorIn_p in the real unit
of the machine.
C03966 String of digits Position unit
• Read only
C03968 Following error out of tolerance
• Read only
FALSE Following error smaller than set
switching threshold
TRUE Following error larger than set
switching threshold
C03969 Following error monitoring activated
• Read only
FALSE Deactivated
TRUE Activated
