9400 Technology applications | Positioning sequence control
Parameter setting & configuration
Parameterisable function blocks
5.14.3 ApplicationError2
5.14.4 FollowingErrorScaling
5.14.5 HysteresisFollowingError1
Is an instance of Function
L_DevApplErr Error handling
Application error messages ( 65)
Parameter Possible settings Information
C05903 980 999 Module ID
• Initialisation: 998
C05904/1...8 0 65535 Error ID
• Initialisation: 8011 ... 8018
C05905/1...8 Error response
0 None
1 Fault
2 Trouble
3 Quick stop by trouble
4 Warning locked
5 Warning
6 Information
Is an instance of Function
L_TbNormalize Scaling of the following error to a parameterisable reference variable
Parameter Possible settings Information
C04035 -2147483647 2147483647 Reference variable
• Setting "0" is not possible.
• Initialisation: 65536
Is an instance of Function
L_SdSetPosition Conversion of the following error hysteresis 1 selected in the real units of the
machine via C03917 into a position in [increments].
Following error monitoring ( 54)
Parameter Possible settings Information
C03917 -214000.0000 unit 214000.0000 Position value
• Initialisation: 0.0000 unit
C03918 String of digits Position unit
• Read only
C03919 -2147483647 2147483647 State
• Read only
