Lenze MC1000 Series User Manual
Page 9
13435742_EDBM101_v24
5
TYPE 1 DIMENSIONS (continued)
HP
(kW)
INPUT
VOLTAGE
MODEL
H
W
D
N
P
Q
R
S
3
(2.2)
240
M1230SB 7.50 6.12 5.12 3.77 3.30 1.37 5.50 0.88
240 / 200 M1230B 7.50 6.12 5.12 3.77 3.30 1.37 5.50 0.88
480 / 400 M1430B 7.50 6.12 5.12 3.77 3.30 1.37 5.50 0.88
590
M1530B 7.50 6.12 5.12 3.77 3.30 1.37 5.50 0.88
5
(3.7)
240 / 200 M1250B 7.88 7.86 5.94 5.13 3.95 1.50 5.88 1.13
480 / 400 M1450B 7.50 6.12 5.12 3.77 3.30 1.37 5.50 0.88
590
M1551B 7.88 7.86 5.94 5.13 3.95 1.50 5.88 1.13
7.5
(5.5)
240 / 200 M1275B 9.38 7.86 6.84 3.93 4.19 2.00 5.88 1.13
480 / 400 M1475B 9.38 7.86 6.25 5.13 3.95 1.50 7.38 1.13
590
M1575B 9.38 7.86 6.25 5.13 3.95 1.50 7.38 1.13
10
(7.5)
240 / 200 M12100B 11.25 7.86 6.84 3.93 4.19 2.00 7.75 1.38
480 / 400 M14100B 9.38 7.86 6.84 3.93 4.19 2.00 5.88 1.13
590
M15100B 9.38 7.86 7.40 3.93 4.19 2.00 5.88 1.13
15
(11)
240/200 M12150B 12.75 7.86 6.84 3.93 4.19 2.00 9.25 1.38
480/400 M14150B 11.25 7.86 6.84 3.93 4.19 2.00 7.75 1.38
590
M15150B 12.75 7.86 6.84 3.93 4.19 2.00 9.75 1.38
20
(15)
240 / 200 M12200B 12.75 10.26 7.74 5.13 5.00 2.50 9.25 1.38
480/400 M14200B 12.75 7.86 6.84 3.93 4.19 2.00 9.25 1.38
590
M15200B 12.75 7.86 7.40 3.93 4.19 2.00 9.25 1.38
25
(18.5)
240 / 200 M12250B 15.75 10.26 8.35 5.13 5.00 2.50 12.25 1.38
480/400 M14250B 12.75 10.26 7.74 5.13 5.00 2.50 9.25 1.38
590
M15250B 12.75 10.26 7.74 5.13 5.00 2.50 9.25 1.38
30
(22)
240 / 200 M12300B 15.75 10.26 8.35 5.13 5.00 2.50 12.25 1.38
480/400 M14300B 12.75 10.26 7.74 5.13 5.00 2.50 9.25 1.38
590
M15300B 12.75 10.26 8.25 5.13 5.00 2.50 9.25 1.38
40
(30)
480/400 M14400B 15.75 10.26 8.35 5.13 5.00 2.50 12.25 1.38
590
M15400B 15.75 10.26 8.35 5.13 5.00 2.50 12.25 1.38
50
(37.5)
480/400 M14500B 19.75 10.26 8.55 5.13 5.75 2.50 16.25 1.75
590
M15500B 19.75 10.26 8.55 5.13 5.75 2.50 16.25 1.75
60
(45)
480/400 M14600B 19.75 10.26 8.55 5.13 5.75 2.50 16.25 1.75
590
M15600B 19.75 10.26 8.55 5.13 5.75 2.50 16.25 1.75
