13.2.4 MC1000 DISPLAY IN AUXILIARY MODE
If the ENTER key is held down, the display will enter the auxiliary mode, which
indicates the control source (LOCAL, REMOTE, or SERIAL), AUTO or MANUAL
mode, and the speed reference source. When the ENTER key is released, the
display will return to the previous screen. An example of the auxiliary mode display
is shown below:
LOCAL -- AUTO -- IDC
CONTROL
SOURCE
AUTO/MAN
MODE
SPEED
REFERENCE
SOURCE
The table below shows the possible SPEED REFERENCE SOURCE indications
for the auxiliary mode display:
SPEED REFERENCE SOURCE TABLE
DISPLAY DESCRIPTION
KEY KEYPAD - Change speed using the p and q keys.
VDC 0 - 10 VDC analog input at TB-5A.
IDC 4 - 20 mA analog input at TB-5B.
SP#1 PRESET SPEED #1
SP#2 PRESET SPEED #2
SP#3 PRESET SPEED #3
SP#4 PRESET SPEED #4
JOG JOG SPEED - In JOG mode, JOG SPEED = PRESET SPEED #2.
MOP
MOTOR OPERATED POT - Change speed using contact closures at
TB-13A (DEC FREQ) and TB-13B (INC FREQ).
