M1200 SERIES RATINGS
MODEL
INPUT
OUTPUT
(200/240 Vac, 50 - 60 Hz)
(0 - 200/230 Vac)
MODEL
NUMBER
1
FOR MOTORS
NOMINAL
NOMINAL
RATED
INPUT CURRENT
2
POWER
CURRENT
POWER
HP
kW
PHASE
(AMPS)
(KVA)
(AMPS)
(KVA)
M1205S
0.5
0.37
1
5.8 / 5.0
1.2
2.5 / 2.2
0.9
M1205
0.5
0.37
3
3.1 / 2.7
1.1
2.5 / 2.2
0.9
M1210S
1
0.75
1
10.4 / 9.0
2.2
4.6 / 4.0
1.6
M1210
1
0.75
3
5.5 / 4.8
2.0
4.6 / 4.0
1.6
M1215S
1.5
1.1
1
13.3 / 11.6
2.8
6.0 / 5.2
2.1
M1215
1.5
1.1
3
7.1 / 6.2
2.6
6.0 / 5.2
2.1
M1220S
2
1.5
1
17.1 / 14.9
3.6
7.8 / 6.8
2.7
M1220
2
1.5
3
9.3 / 8.1
3.4
7.8 / 6.8
2.7
M1230S
3
2.2
1
24 / 21
5.0
11.0 / 9.6
3.8
M1230
3
2.2
3
13.0 / 11.3
4.7
11.0 / 9.6
3.8
M1250
5
3.7
3
20 / 17.7
7.4
17.5 / 15.2
6.1
M1275
7.5
5.5
3
30 / 26
10.6
25 / 22
8.8
M12100
10
7.5
3
37 / 32
13.2
32 / 28
11.2
M12150
15
11
3
55 / 48
19.8
48 / 42
16.7
M12200
20
15
3
70 / 61
25.3
62 / 54
21.5
M12250
25
18.5
3
89 / 77
32.0
78 / 68
27.1
M12300
30
22
3
104 / 90
37.6
92 / 80
31.9
M12400
3
40
30
3
119 / 99
41.0
120 / 104
41.4
M12600
3
60
45
3
174 / 145
60.5
177 / 154
61.3
1
Refer to Section 3 for model number breakdown.
2
Refer to Section 8 for recommended fuse type.
3
For branch circuit protection, the 40HP and 60HP 230V models must only be
installed with the appropriately rated UL Listed fuses.
