17
PARAMETER MENU
NOTE 1:
REFER TO SECTION 18 - DESCRIPTION OF PARAMETERS
NOTE 2:
MAX LIMIT IS 650 Hz ON UNITS WITH HIGH FREQUENCY SOFTWARE
NOTE 3:
IF LINE VOLTS IS SET TO "LOW" (OR SET TO "AUTO" AND THE INPUT
VOLTAGE IS LOW), THE RANGE IS 25 - 150%.
PARAMETER MENU
PARAM.
NUMBER
PARAMETER
NAME
RANGE OF
ADJUSTMENT
FACTORY
DEFAULT
0
LINE VOLTS
HIGH, LOW, AUTO
AUTO
1
SPEED #1
MIN FRQ - MAX FRQ
20.00 Hz
2
SPEED #2
MIN FRQ - MAX FRQ
20.00 Hz
3
SPEED #3
MIN FRQ - MAX FRQ
20.00 Hz
4
SPEED #4
MIN FRQ - MAX FRQ
20.00 Hz
5
SKIP #1
0.00 Hz - MAX FRQ
0.00 Hz
6
SKIP #2
0.00 Hz - MAX FRQ
0.00 Hz
7
BAND WID
0.00 - 10.00 Hz
1.00 Hz
8
ACCEL
(NOTE 1)
30.0 SEC
9
DECEL
(NOTE 1)
30.0 SEC
10
MIN FRQ
0.00 - MAX FRQ
0.50 Hz
11
MAX FRQ
MIN FREQ - 120.0 Hz (NOTE 2)
60.00 Hz
12
DC BRAKE
(NOTE 1)
0.0 VDC
13
DC TIME
0.0 - 999.9 SEC
0.0 SEC
14
DYN BRAKE
OFF, ON
OFF
16
CURRENT
25 - 180 % (NOTE 3)
180 %
17
MOTOR OL
25 - 100 %
100 %
18
BASE
20.00 - 360.0 Hz (NOTE 2)
60.00 Hz
19
FX BOOST
0.0 - 30.0 %
(NOTE 1)
20
AC BOOST
0.0 - 20.0 %
0.00 %
21
SLIP CMP
0.0 - 5.0 %
0.00 %
22
TORQUE
CONSTANT, VARIABLE,
CT / NOCMP
CONSTANT
23
CARRIER
2.5, 6, 8, 10, 12, 14 kHz
2.5 kHz
25
START
NORMAL, POWER UP,
AUTO RE-, RE-BRAKE
NORMAL
26
STOP
COAST, RAMP, RAMP 2
COAST
27
ROTATION
FORWARD, REVERSE,
FWD&REV, FWD@LOC
FORWARD
