The following table shows the possible DRIVE STATUS indications that can appear
on the drive display:
DRIVE STATUS TABLE
DISPLAY DESCRIPTION
STOP Drive to STOP mode - No output to motor.
RUN Drive is in RUN mode and is within + 0.3 Hz of the speed set point.
FAULT
Drive has shut down due to a FAULT condition. If the fault condition has
passed, pressing the STOP key will clear the fault and return the drive to the
STOP mode.
LOCK Drive is in FAULT LOCKOUT after five unsuccessful restart attempts.
BRAKE DC BRAKE is energized.
LIMIT
Drive is in CURRENT LIMIT due to an overloaded motor,
or ACCEL is set too fast.
F DEC Drive is in DECEL FREEZE because DECEL is set too fast.
13.2.2 MC1000 DISPLAY IN RUN MODE
When the drive is in the RUN mode, the default display will look like this:
RUN > 60.00 HZ
DRIVE
STATUS
SPEED
SET POINT
SPEED
UNITS
DIRECTION
(FORWARD)
As in the STOP mode, the ENTER key can be used to toggle the display from
SPEED to % LOAD to VAC (motor voltage):
RUN > 85% LOAD
DRIVE
STATUS
PERCENT
LOAD
DIRECTION
(FORWARD)
