60 13435742_EDBM101_v24
47 TB13A (TB-13A INPUT FUNCTION)
This parameter is used to select the function of terminal TB-13A. Closing TB-13A
to TB-2 activates the TB-13A input function.
The following functions can be selected:
NONE
Disables the TB-13A function.
0-10VDC Selects 0-10 VDC as the AUTO speed reference input. The
0-10 VDC signal is wired to TB-5A and TB-2.
4-20 MA Selects 4-20 mA as the AUTO speed reference input. The 4-20
mA signal is wired to TB-5B and TB-2.
SPEED#1 Selects PRESET SPEED #1 as the AUTO speed reference.
LOC SEL Selects LOCAL mode when Parameter 30 - CONTROL is set
to BOTH. Drive is in REMOTE mode if contact closure is not
made.
DEC FREQ Decrease frequency set point. Used with the MOP (motor
operated pot) function. Refer to Section 14.2.6 - SPEED
REFERENCE SELECTION.
48 TB13B (TB-13B INPUT FUNCTION)
WARNING!
When operating in JOG mode, the STOP key WILL NOT stop the
drive. To stop the drive, the contact between TB-13B and TB-2 must
be opened.
This parameter is used to select the function of terminal TB-13B. Closing TB-13B
to TB-2 activates the TB-13B function. The following functions can be selected:
NONE
Disables the TB-13B function.
0-10VDC Selects 0-10 VDC as the AUTO speed reference input. The
0-10 VDC signal is wired to TB-5A and TB-2.
4-20 MA Selects 4-20 mA as the AUTO speed reference input. The 4-20
mA signal is wired to TB-5B and TB-2.
SPEED#2 Selects PRESET SPEED #2 as the AUTO speed reference.
INC FREQ Increase frequency set point. Used with the MOP (motor
operated pot) function. Refer to Section 14.2.6 - SPEED
REFERENCE SELECTION.
JOG FWD Jog in the forward direction. Active only when drive is STOPPED.
The jog speed is set by Parameter 2 -SPEED#2.
JOG REV Jog in the reverse direction. Active only when drive is STOPPED.
The jog speed is set by Parameter 2 - SPEED#2.
49 TB13C (TB-13C INPUT FUNCTION)
WARNING!
If TB-13C is programmed for RUN REVERSE, TB-1 is disabled and
CANNOT be used as a STOP switch! This is true in LOCAL and
REMOTE mode. Incorrect use of TB-1 may result in damage to
equipment and/or injury to personnel!
