Leica Angle Two ™ User Manual Rev A02 © Leica Biosystems Richmond Inc. 2010 48
8
Specifications
Instrument Dimensions
Resolution, Linear Scales
Drive Advancement per Revolution
Manipulator Movement
Base width 253 mm
Base length 355 mm
Base height 20 mm
U frame width 165 mm
U frame length 200 mm
U frame height 55 mm
Base and manipulator height 381 mm
Base weight (no manipulator) 6.1 kg
Vernier 0.1 mm
Digital display
0.01 mm
Internal scale 0.005/rev
Linear axis drive (screw pitch) 5 mm/rev
Fine drive 0.25 mm/rev
AP 67 mm
ML 80 mm
DV 57 mm
Tilt
±90° ML or AP axis, or combined
Rotation 360°
Rotary encoder resolution 1000 lines/rev. (0.36°)
