Leica Biosystems ANGLE TWO User Manual
Page 14

Components
Leica Angle Two
™
User Manual Rev A02 © Leica Biosystems Richmond Inc. 2010
14
Each linear movement is controlled by a coarse drive and, in the DV direction, by an additional fine
drive. When locating the target site, first use the ML and AP coarse drives to move the probe into
place above the target. Then lower the probe until it reaches the brain using the coarse DV drive.
Finally, engage the fine drive to continue DV movements to the target within the brain.
Figure 9. The AP, ML, DV and fine drives move the probe in linear movements
Caution
Do not continue to turn the drives at the end of their movement range, as it will damage the nut
below.
DV drive
ML drive
AP drive
Fine drive
