5-2 F-701
GENERAL REFERENCE AND SPECIFICATIONS
Figure 5-2: WFP30-36
WFPD30 / WFPDS30 /
WFPO30
WFPD32 / WFPDS32 /
WFPO32
WFPD34 / WFPDS34 /
WFPO34
WFPD36 / WFPDS36 /
WFPO36
Approximate Weight
WFPD30: 8,000 lbs. (3,629 kg) WFPD32: 8,300 lbs. (3,765 kg) WFPD34: 8,650 lbs. (3,924 kg) WFPD36: 9,000 lbs. (4,082 kg)
WFPDS30: 8,250 lbs. (3,742 kg) WFPDS32: 8,600 lbs. (3,901 kg) WFPDS34: 8,950 lbs. (4,060 kg) WFPDS36: 9,300 lbs. (4,218 kg)
WFPO30: 8,343 lbs. (3,784 kg) WFPO32: 8,720 lbs. (3,955 kg) WFPO34: 9,093 lbs. (4,125 kg) WFPO36: 9,393 lbs. (4,261 kg)
Approximate Tongue Weight
Drawbar Retracted, Transport 1,800 lbs. (816 kg) 1,850 lbs. (839 kg) 1,850 lbs. (839 kg) 1,850 lbs. (839 kg)
Drawbar Extended, Transport 1,400 lbs. (635 kg) 1,500 lbs. (680 kg) 1,500 lbs. (680 kg) 1,500 lbs. (680 kg)
Operation <100 lbs. (45 kg) <100 lbs. (45 kg) <100 lbs. (45 kg) <100 lbs. (45 kg)
Working Width 31 ft. 4 in. (9.6 m) 33 ft. 4 in. (10.2 m) 35 ft. 4 in. (10.8 m) 37 ft. 4 in. (11.4 m)
Transport Width 14 ft. 0 in. (4.3 m) 14 ft. 0 in. (4.3 m) 14 ft. 0 in. (4.3 m) 14 ft. 0 in. (4.3 m)
Transport Height 9 ft. 8 in. (2.9 m) 10 ft. 2 in. (3.1 m) 10 ft. 6 in. (3.2 m) 10 ft. 10 in. (3.3 m)
Overall Length, Drawbar Retracted 17 ft. (5.2 m) 17 ft. (5.2 m) 18 ft. (5.5 m) 18 ft. (5.5 m)
Overall Length, Drawbar Extended 22 ft. (6.7 m) 22 ft. (6.7 m) 23 ft. (7.0 m) 23 ft. (7.0 m)
Overall Length, Rigid Drawbar N/A N/A N/A N/A
Road Clearance 11.5 in. (292 mm) 11.5 in. (292 mm) 11.5 in. (292 mm) 11.5 in. (292 mm)
Automatic Transport Lock Standard Standard Standard Standard
Hydraulic Circuits Required 1 1 1 1
Pulverizer Wheels
WFPD Series 20" (500 mm) Notched Ductile Iron 20" (500 mm) Notched Ductile Iron 20" (500 mm) Notched Ductile Iron 20" (500 mm) Notched Ductile Iron
WFPO Series 20" (500 mm) Optimizer Ductile Iron 20" (500 mm) Optimizer Ductile Iron 20" (500 mm) Optimizer Ductile Iron 20" (500 mm) Optimizer Ductile Iron
Number of Wheels
WFPD30, WFPDS30: 96 WFPD32, WFPDS32: 102 WFPD34, WFPDS34: 108 WFPD36, WFPDS36: 114
WFPO30: 63 WFPO32: 67 WFPO34: 71 WFPO36: 75
Axle Size 8 in. (203 mm) 8 in. (203 mm) 8 in. (203 mm) 8 in. (203 mm)
Hitch Pull-Type with Hydraulic Transport Pull-Type with Hydraulic Transport Pull-Type with Hydraulic Transport Pull-Type with Hydraulic Transport
Tire Size 11L x 15-8 Ply Implement Rib 11L x 15-8 Ply Implement Rib 11L x 15-8 Ply Implement Rib 11L x 15-8 Ply Implement Rib
Safety Warning Lights &
SMV Emblem
Standard Standard Standard Standard
Scraper Kit Standard on Models with "S" Standard on Models with "S" Standard on Models with "S" Standard on Models with "S"
Safety Chain Kit Standard Standard Standard Standard
Horsepower Requirements 100 HP (74.6 kW) 100 HP (74.6 kW) 100 HP (74.6 kW) 100 HP (74.6 kW)
Horsepower Requirements
As Companion
1 HP per ft. (2.5 kW per m) 1 HP per ft. (2.5 kW per m) 1 HP per ft. (2.5 kW per m) 1 HP per ft. (2.5 kW per m)
Recommended Operating Speed 3 to 7.5 MPH (4.8 to 12.1 km/h) 3 to 7.5 MPH (4.8 to 12.1 km/h) 3 to 7.5 MPH (4.8 to 12.1 km/h) 3 to 7.5 MPH (4.8 to 12.1 km/h)
