ASSEMBLY
2-9
Figure 2-8: Hydraulic Schematic
**Hose
Asm,3/8 x 250
P/N 175104
(Rigid Drawbar)
**Hose
Asm,3/8 x 284
P/N 174945
(T
elescoping Drawbar)
Hose
Asm,3/8 x 36
P/N 170508
RH
LH
Retrictor
,
08MJ x 08MOR
P/N 4K607
Hose
Asm,3/8 x 70
P/N 175107
Hose
Asm,3/8 x 56
P/N 123547
4 x 36 Hyd Cyl
P/N 2P460
Elbow
,08MJ x
08MOR x 90° P/N 2062-8-8S
4 x 36 Hyd Cyl
P/N 2P460
Retrictor
,
08MJ x 08MOR
P/N 4K607
Retrictor
,
08MJ x 08MOR
P/N 4K607
Elbow
,08MJ x
08FJS x 90°
P/N 2071-8-8S
4 x 16 Hyd Cyl
P/N 9D731
**
Bulkhead,08MJ
P/N 102-0322
Hydraulic Schematic
** Denote pre-assembled
parts on Drawbar
Male
T
ractor
T
ip
P/N 141828
Female Coupler
P/N 142668
Female Coupler
P/N 142668
Elbow
,08MOR x
08FJS x 90° P/N 2P140
Elbow
,08MOR x
08FJS x 90° P/N 2P140
**Male
T
ractor
T
ip
P/N 141828
Elbow
,08MJ x
08FJS x 90°
P/N 2071-8-8S
Hose
Asm,3/8 x 24
P/N 147582
Hose
Asm,3/8 x 30
P/N 71508985
Elbow
,08MJ x
08FJS x 90° P/N 2071-8-8S
Hose
Asm,3/8 x 27
P/N 123062
Elbow
,08MJ x
08FJS x 90°
P/N 2071-8-8S
Manifold P/N 164763
PLUG,08MOR P/N102-1
187
Plug,08MOR P/N 102-1
187
Tee,08MJx08MOR Run
P/N 203005-8-8S
Elbow
,08MJ x
08MOR x 90° P/N 2062-8-8S
Shut-of
f V
alve
Cartridge
P/N 171000
Relief V
alve Cartridge P/N 175159
Adapter
,08MJ x 08MOR
P/N 202702-8-8S
DO NOT
Attach to
T
ractor
until
All hoses have been connected.
