Page 37: Chapter 3
3-1
Chapter 3
Operation
NOTE
This chapter will cover the basic operation and
procedures for the Landoll Brillion Wing Float Pulverizer.
Be sure to read and understand the Safety Procedures
and Cautions starting on page 1-2.
Before operating your Brillion machine check all
hardware for tightness. Use the Torque Tightening Chart
as a guide. See page 4-1.
Field Operations
Once the Wing Float Pulverizer has been transported to
the field, remove the Transport Lock Pin from the
Transport Linkage and store it in the Plate Bracket.
WARNING
Transport Lock
To prepare the machine for transport, raise it fully and
install the pin. See Figure 3-1. The rear-most hole is used
for pin storage during field operations.
Figure 3-1: Transport Lock
Watch out for Overhead Electrical Wires and
other Overhead Obstructions when folding and
unfolding Pulverizer Wings.
Transport Position
Storage Position
Plate
