Landoll WFPC22-36 Wing Float Pulverizer User Manual
Page 34
2-20
F-701
ASSEMBLY
Figure 2-18: LED Warning Lights Installation
WFP22-36RepLEDElectLayout
Screw
,1/4-20 X 1-1/2
Locknut,1/4-20
Locknut,5/16-18
SMV
W
asher
,5/16
Screw
,
5/16-18 X 1-1/4
Amber
LED
Screw
,
1/4-20 X 1-1/2
Light Shield
Locknut,1/4-20
Locknut,1/4-20
Red LED
Screw
,
1/4-20 X 1-1/2
7 Pin Harness
Light Module
Lamp Harness
