5-1
Chapter 5
General Reference and Specifications
Model Designation
• Basic model is denoted by “WFP” - Wing Float
Pulverizer.
• Axle Wheel type is denoted by “D” - Ductile 20”
Notched.
• Scrapers are standard on models denoted by “S”.
• Approximate working rolling width is denoted by the
last digits in Model Number representing feet.
Figure 5-1: WFP22-28
WFPD22 / WFPDS22 /
WFPO22
WFPD24 / WFPDS24 /
WFPO24
WFPD26 / WFPDS26 /
WFPO26
WFPD28 / WFPDS28 /
WFPO28
Approximate Weight
WFPD22:
6,550
lbs.
(2,971
kg)
WFPD24:
6,850
lbs.
(3,107
kg)
WFPD26:
7,100
lbs.
(3,221
kg)
WFPD28:
7,600 lbs. (3,447 kg)
WFPDS22: 6,700
lbs.
(3,039
kg)
WFPDS24: 7,050
lbs.
(3,198
kg)
WFPDS26: 7,350
lbs.
(3,334
kg)
WFPDS28: 7,850 lbs. (3,561 kg)
WFPO22:
6,813
lbs.
(3,090
kg)
WFPO24:
7,108
lbs.
(3,224
kg)
WFPO26:
7,407
lb.
(3,360
kg)
WFPO28:
7,987 lbs. (3,623 kg)
Approximate Tongue
Weight
Drawbar Retracted,
Transport
N/A
N/A
N/A
1,800
lbs. (816 kg)
Drawbar Extended,
Transport
1,300
lbs.
(590
kg)
1,300
lbs.
(590
kg)
1,300
lbs.
(590
kg)
1,400
lbs. (635 kg)
Operation
<100
lbs.
(45
kg)
<100
lbs.
(45
kg)
<100
lbs.
(45
kg)
<100
lbs. (45 kg)
Working Width
23
ft. 4
in. (7.1
m)
25
ft. 4
in. (7.7 m)
27
ft. 4
in.
(8.3
m)
29
ft. 4
in. (8.9 m)
Transport Width
14
ft. 0
in. (4.3
m)
14
ft. 0
in. (4.3
m)
14
ft. 0
in. (4.3
m)
14
ft. 0
in. (4.3 m)
Transport Height
8 ft. 4
in.
(2.5
m)
8 ft. 8
in.
(2.6
m)
9 ft. (2.7 m)
9 ft. 4
in. (2.8 m)
Overall Length,
Drawbar
Retracted
N/A
N/A
N/A
17
ft. (5.2 m)
Overall Length,
Drawbar
Extended
N/A
N/A
N/A
22
ft. (6.7 m)
Overall Length,
Rigid
Drawbar
21
ft. (6.4
m)
21
ft. (6.4
m)
21
ft. (6.4
m)
N/A
Road Clearance
11.5
in.
(292
mm)
11.5
in.
(292
mm)
11.5
in.
(292
mm)
11.5
in.
(292 mm)
Automatic Transport
Lock
Standard
Standard
Standard
Standard
Hydraulic Circuits
Required
1
1
1
1
Pulverizer Wheels
WFPD Series
20"
(500
mm)
Notched
Ductile
Iron
20"
(500
mm)
Notched
Ductile
Iron
20"
(500
mm)
Notched
Ductile
Iron
20"
(500
mm)
Notched Ductile Iron
WFPO Series
20"
(500
mm)
Optimizer
Ductile
Iron
20"
(500
mm)
Optimizer
Ductile
Iron
20"
(500
mm)
Optimizer
Ductile
Iron
20"
(500
mm)
Optimizer Ductile Iron
Number of Wheels
WFPD22,
WFPDS22:
72
WFPD24,
WFPDS24:
78
WFPD26,
WFPDS26:
84
WFPD28,
WFPDS28: 90
WFPO22:
47
WFPO24:
51
WFPO26:
55
WFPO28: 59
Axle Size
8
in.
(203
mm)
8
in.
(203
mm)
8
in.
(203
mm)
8
in.
(203 mm)
Hitch
Pull-Type
with Hydraulic Transport
Pull-Type
with Hydraulic Transport
Pull-Type
with Hydraulic Transport
Pull-Type
with Hydraulic Transport
Tire Size
11L
x 15-8
Ply Implement
Rib
11L
x 15-8
Ply Implement
Rib
11L
x 15-8
Ply Implement
Rib
11L
x 15-8
Ply Implement Rib
Safety Warning
Lights
&
SMV Emblem
Standard
Standard
Standard
Standard
Scraper Kit
Standard
on
Models
with
"S"
Standard
on
Models
with
"S"
Standard
on
Models
with
"S"
Standard
on
Models with "S"
Safety Chain Kit
Standard
Standard
Standard
Standard
Horsepower Requirements
100 HP (74.6 kW)
100 HP (74.6 kW)
100 HP (74.6 kW)
100 HP (74.6 kW)
Horsepower Requirements
As Companion
1 HP per ft. (2.5 kW per m)
1 HP per ft. (2.5 kW per m)
1 HP per ft. (2.5 kW per m)
1 HP per ft. (2.5 kW per m)
Recommended Operating Speed
3 to 7.5 MPH (4.8 to 12.1 km/h)
3 to 7.5 MPH (4.8 to 12.1 km/h)
3 to 7.5 MPH (4.8 to 12.1 km/h)
3 to 7.5 MPH (4.8 to 12.1 km/h)
