OPERATION
3-3
Transporting on Roadways
Fold wings completely. Make sure the Wing Cylinders are retracted completely and the Transport Axle Cylinder is
extended. Remove the Transport Lock Pin from the plate and insert it into the Transport Linkage. See Figure 3-3.
Figure 3-3: Road Transport
Transporting on a Trailer
Step 1. With the Pulverizer fully raised and wings folded, close the Fold Shut-off Valve completely. See Figure 2-11.
Step 2. Disconnect Drawbar from tractor. Step 3. Retract Telescoping Drawbar. Step 4. Disconnect (Quick Coupling)
Hydraulic Hoses and the Ag Harness where the frame connects to the drawbar. Step 5. Remove Turnbuckle and the
Drawbar Pins. See Figure 3-4.
Figure 3-4: Trailer Transport
Plate
Transport Position
Storage Position
Remove Drawbar Pins
Remove
Turnbuckle Pins
Disconnect
Hydraulic Hoses
Disconnect
Ag Harness
