Vacuum Fan/Manifold Mounting Supports and Hardware
ITEM PART NO. QTY. DESCRIPTION
1 --- - See “Vacuum Fan Assembly, 24 Row 30" and 36 Row 20"” on page P47
2 --- - See “Manifolds and Distribution Hoses, 24 Row 30"” on page P61
See “Manifolds and Distribution Hoses, 36 Row 20"” on page P63
3 G10023
G10110 -
- Hex Head Cap Screw, ¼"-20 x ¾"
Lock Nut, ¼"-20, Grade B
4 GD16842 2 Manifold Gasket, ⅛" x 8 ⅜" (6⅝" I.D.)
5 G11199
GD8893-07 1
1 Whiz Lock Bolt, ⅜"-16 x 2"
Sleeve, 1" Long
6 GA13181 1 Support
7 G10341
G10152 -
- Hex Head Cap Screw, ⅝"-11 x 8"
Hex Head Cap Screw, ⅝"-11 x 9"
8 G10574
G10071 4
4 Carriage Bolt, ½"-13 x 1¼"
Serrated Flange Nut, ½"-13
9 GD18628 - Tap Plate, Short
10 GD18626 - Support
11 GD15854 1 Clamp
12 G10338
G10620 -
- Carriage Bolt, 5∕16"-18 x 1¼"
Serrated Flange Nut, 5∕16"-18
13 G11145 - T-Bolt Clamp, 7"
14 G10133
G10232
G10106 -
-
- Hex Head Cap Screw, 5∕16"-18 x 1½"
Lock Washer, 5∕16"
Hex Nut, 5∕16"-18
15 GA11164 - Mount
16 GD18624 - Tap Block
17 GA13203 - Offset Support
18 GD18625 - Offset Support
19 GD18627 - Tap Block, Long
20 GD18622 - Block Support Plate
21 GD8893-10 - Sleeve, 913∕16" Long
22 G10980
GD18623 -
- Hex Head Cap Screw, ½"-13 x 5½"
Cap Screw, ½"-13 x 17"
23
G11257
G10108 -
- Hex Head Cap Screw, ⅜"-16 x 11½"
Lock Nut, ⅜"-16
24 G10063
G10753
G10229
G10101 -
-
-
- Hex Head Cap Screw, ⅜"-16 x 4"
Hex Head Cap Screw, ⅜"-16 x 4½"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
25 G10001
G10108 -
- Hex Head Cap Screw, ⅜"-16 x 1"
Lock Nut, ⅜"-16
Model 3700 M0233-02
Rev. 9/11 P70
