Kinze 3700 Front Folding Planter Rev. 6/14 - Manual (Page 103)

ASD Catwalk, 24 Row 20" and 24 Row 22"
ITEM PART NO. QTY. DESCRIPTION
1 GA16693 1 Front Hand Rail Post
2 G11360 4 T-Bolt Hose Clamp, 4½"
3 GA14097
G10305
G11091 1
4
4 Front Handrail
Carriage Bolt, ⅜"-16 x 1"
Serrated Flange Nut, ⅜"-16
4 GD8306
G10071 2
4 U-Bolt, 7" x 5" x ½"-13
Serrated Flange Nut, ½"-13
5 GD19972
G10305
G11091 2
4
4 Front Catwalk Mount Plate
Carriage Bolt, ⅜"-16 x 1"
Serrated Flange Nut, ⅜"-16
6 G10037
G10071 2
2 Hex Head Cap Screw, ½"-13 X 1¼"
Serrated Flange Nut, ½"-13
7 GA14246 1 Front Catwalk
8 GD20356
G10305
G11091 1
4
4 Ladder Latch
Carriage Bolt, ⅜"-16 x 1"
Serrated Flange Nut, ⅜"-16
9 GA14224
G10305
G11091 1
6
6 R.H. Front Handrail
Carriage Bolt, ⅜"-16 x 1"
Serrated Flange Nut, ⅜"-16
10 G10478
GD5857 2
1 Clevis Pin, 5⁄16" x 1"
Spring
11 G10046
G10205
G10107 1
2
1 Hex Head Cap Screw, ⅝"-11 x 5"
Washer, ⅝" SAE
Lock Nut, ⅝"-11
12 GD3180-32 1 Sleeve, ⅞" O.D. x .635 I.D. x 2½"
13 GA14242 1 Latch
14 GA14222
G10305
G11091 1
4
4 R.H. Rear Handrail
Carriage Bolt, ⅜"-16 x 1"
Serrated Flange Nut, ⅜"-16
15 GA14244 1 Rear Catwalk
16 G10005
GB0218
G10107 2
2
2 Hex Head Cap Screw, ⅝"-11 x 1 ¾"
Bushing, 21⁄32" I.D. x ⅞" O.D. x 19⁄32" Long
Lock Nut, ⅝"-11
17 GA14240
G10451
G10305
G11091 1
1
2
2 Latch Mount
Cotter Pin, ⅛" x 1"
Carriage Bolt, ⅜"-16 x 1"
Serrated Flange Nut, ⅜"-16
18 GA14243 1 Ladder
19 GA14241 1 Latch Handle
20 GD20252
G10451
G10203 1
2
2 Latch Stabilizer
Cotter Pin, ⅛" x 1"
Washer, ⅜" SAE
21 GD20270 1 Latch Plate
22 GD9542-05
G10460 1
2 Pin, 1¼" x 11¾"
Cotter Pin, ¼" x 2"
23 GA14223
G10305
G11091 1
4
4 L.H. Rear Handrail
Carriage Bolt, ⅜"-16 x 1"
Serrated Flange Nut, ⅜"-16
24 GD19971
G10305
G11091 1
6
6 Rear Catwalk Mount Plate
Carriage Bolt, ⅜"-16 x 1"
Serrated Flange Nut, ⅜"-16
25 GA14225
G10305
G11091 1
6
6 L.H. Front Handrail
Carriage Bolt, ⅜"-16 x 1"
Serrated Flange Nut, ⅜"-16
Model 3700 M0233-02
Rev. 12/12 P100
TM
