ITEM PART NO. QTY. DESCRIPTION
27 G1K248
G1K362
-
-
3-Pin Female Connector Kit (Black), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
3-Pin Female Connector Kit (Blue), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
28 G1K252
G1K363
-
-
3-Pin Male Connector Kit (Black), Includes: (3) 3-Pin Male Housings, (9) Socket
Contacts, (9) Seals
3-Pin Male Connector Kit (Blue), Includes: (3) 3-Pin Male Housings, (9) Socket
Contacts, (9) Seals
29 GD11089 - Sealing Plug
30 G1K249 - Acre Counter Switch Kit
31 GA8046
GA9978 -
- Dust Plug (Black)
Dust Plug (Blue)
32 GA8047
GA9979 -
- Dust Plug (Black)
Dust Plug (Blue)
33 GR1415 1 Rotation Sensor
34 GR1414 1 Actuator
35 GD11474 4 Cover
36 G10927
G10931
G10928 4
4
4 Pan Head Machine Screw, No. 8-32 x 1¼", Stainless Steel
Lock Washer, No. 8, Internal/External, Stainless Steel
Hex Nut, No. 8-32, Stainless Steel
37 GD18168 2 Mount
38 G10686
G10229
G10101 4
4
4 Hex Head Cap Screw, ⅜"-16 x 8"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
39 GD18118 2 Shaft Sensor Mount
40 G11288
G10243
G10758 4
4
4 Pan Head Screw, No. 10-32 x 1½"
Washer, No. 10 SAE
Hex Nut, No. 10-32
A GA6147 - Magnetic Distance Sensor And Mounting Package (Items 4-9)
B GA13521 - Shaft Sensor Mounting Package (Items 35-40)
C GA8135 - Shaft Rotation Kit, Includes: (2) Actuators (2) Rotation Sensors
KPM III Electronic Seed Monitor
TM
M0233-02 Model 3700
P205 Rev. 8/12
