Kinze 3700 Front Folding Planter Rev. 6/14 - Manual (Page 211)

Planter Monitor Module (PMM)
ITEM PART NO. QTY. DESCRIPTION
1 G10686
G10229
G10101 4
4
4 Hex Head Cap Screw, ⅜"-16 x 8"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
2 GD18118 2 Shaft Sensor Mount
3 GR1415 1 Rotation Sensor
4 GR1414 1 Actuator
5 GD18168 2 Mount
6 G10757
G10243
G10758 2
2
2 Pan Head Screw, No. 10-32 x 1¼"
Washer, No. 10 SAE
Hex Nut, No. 10-32
7 GD11474 4 Cover
8 G10927
G10931
G10928 4
4
4 Pan Head Machine Screw, No. 8-32 x 1¼", Stainless Steel
Lock Washer, No. 8, Internal/External, Stainless Steel
Hex Nut, No. 8-32, Stainless Steel
9 GA5600 1 Magnetic Distance Sensor
10 GD8751 - Magnetic Distance Sensor Pulse Wheel
11 GD6291 - Insulated Clamp, ⅜"
12 G10001
G10229
G10101 2
2
2 Hex Head Cap Screw, ⅜"-16 x 1"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
13 GD8770 1 Bracket
14 GD8771 1 Spring Wave Washer
15 GA8046
GA9978 -
- Dust Plug (Black)
Dust Plug (Blue)
16 GA8047
GA9979 -
- Dust Plug (Black)
Dust Plug (Blue)
17 G1K248
G1K362
-
-
3-Pin Female Connector Kit (Black), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
3-Pin Female Connector Kit (Blue), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
18 G1K252
G1K363
-
-
3-Pin Male Connector Kit (Black), Includes: (3) 3-Pin Male Housings, (9) Socket
Contacts, (9) Seals
3-Pin Male Connector Kit (Blue), Includes: (3) 3-Pin Male Housings, (9) Socket
Contacts, (9) Seals
19 GD11089 - Sealing Plug
20 GD18013
G10031
GD11963-01
G10620 1
4
4
8 Bracket
Hex Head Cap Screw, 5⁄16"-18 x 1 ¾"
Spacer, 11⁄16"
Serrated Flange Nut, 5⁄16"-18
21 GA12538
G10991 1
4 Planter Monitor Module
Hex Head Cap Screw, 5⁄16"-18 x ⅞"
22 GD19759 2 Module Bracket Mount, 24 Row 30" and 36 Row 20"
23 GD18901 2 Tap Block, Long
24 GA12563 1 Module Cover Assembly W/Lock Clamps
25 G10152 4 Hex Head Cap Screw, ⅝"-11 x 9"
26 GA12655 1 Implement Cable (16 Row)
27 GR0594 - Brush
28 GA7852
GA8050
GD11993 2
-
Planter Harness W/Dust Caps, 24 Row (20 Connectors)
Planter Harness W/Dust Caps, 36 Row (22 Connectors)
Dust Cap
29 GA19961
GA19960 -
- Seed Tube W/Computerized Sensor
Seed Tube (With Holes For Sensor Installation)
30 GA7859 1 Magnetic Distance Sensor Adapter (Analog To Digital)
31 GD24362 2 Module Extension (ASD only)
32 G10133
G10620 4
4 Hex Head Cap Screw, 5⁄16"-18 x 1½"
Serrated Flange Nut, 5⁄16"-18
33 GD18628 2 Short Tap Block, 24 Row 20" and 24 Row 22"
34 GA16923 - Dickey John Adapter Cable
A GA6147 - Magnetic Distance Sensor And Mounting Package (Items 9-14)
Model 3700 M0233-02
Rev. 6/14 P208
