Ag Leader Electric Clutch Package
ITEM
PART NO.
QTY.
DESCRIPTION
1
GA16831
GA12551
1
-
ISOBUS Integra Display Cable
Cobalt Display Cable
2
GD18176
1
Y-Splice Connector
3
GA12596
1
Radar Adapter Cable
4
GA13204
Hall Effect Sensor
5
GA16826
-
Implement Switch Extension Cable
6
---
-
---
7
---
-
---
8
GA12564
1
Seed Rate Control Module
9
GA12537
1
Clutch Control Module
10
GA16386
GA17012
1
-
Section Adapter Cable, 24 Row (2 Row)
Section Adapter Cable, 36 Row (3 Row)
11
GA16374
-
See “Ag Leader Electric Clutch” on page P9
12
---
-
---
13
GA18402
GA18403
1
Clutch Cable, 24 Row
Clutch Cable, 36 Row
14
GA12558
1
Can Stub Cable, 8"
15
GA12559
1
Can Extension Cable, 5"
16
GA12566
1
Cab Stub Cable, 6" (Hydraulic Drive)
17
GA12567
1
Can Extension Cable, 4" (Hydraulic Drive)
18
GA16351
1
Planter Monitor Module
19
GA16352
1
PMM Cable
20
GA12655
1
Implement Cable
21
GA14450
1
CAN Adapter Cable
22
GA14452
GA12562
1
Power Cable (Integra)
Power Cable (Cobalt)
23
GA12598
1
Seed Rate Power Cable
24
GA12540
1
Power Control Relay
25
GA16829
-
26
*GA14447
*GA13554
-
-
Integra Loaner Display (Display Only) (Shown)
Cobalt Display
27
GA16344
GA16345
-
-
R.H. Seed Rate Cable
L.H. Seed Rate Cable
28
---
-
See “Hydraulic Motor” on page P186
29
GA12565
-
Encoder Module
See “Miscellaneous Cobalt and Integra Parts” on page P206
for mounting brackets.
Model 3700
M0233-02
Rev. 12/12
P218
