Transport Wheel and Hub Assembly
ITEM PART NO. QTY.
(Per Assy.)
DESCRIPTION
1 G10376 4 Hex Head Cap Screw, 5∕16"-18 x ¾"
2 GD1529 1 Dust Cap
3 GD1536 1 Seal
4 G10460 1 Cotter Pin, ¼" x 2"
5 G10070 1 Slotted Hex Nut, 1¼"-12
6 GD24082 2 Washer
7 GA0705 1 Outer Bearing
8 GA5965
GR0322
GD8532
G10373
GR0257 1
-
-
-
-
Hub W/Cups, Grease Fitting And Stud Bolts (10 Bolt)
Outer Cup
Inner Cup
Grease Fitting, 45°, ⅛"-27
Stud Bolt, ¾"-16 x 2½"
9 GA5987 1 Inner Bearing
10 GA5988 1 Seal
11 GD13352 - Tire, 36" x 16" x 17.5", 14 Ply, Tubeless (Specify Brand*)
12 GD9509 10 Outer Budd Nut
13 GA6738
GA7448 -
- Rim, 18½" Deep, 24 Row 30"
Rim, 16" Deep, 24 Row 20" and 24 Row 22"
14 GD9508
GD12567 10
-
Inner Budd Nut, 2¼" Long
Inner Budd Nut, 2⅝" Long
15 GA7434 1 Valve Stem
16 GR2079 4 Hex Bolt, 5⁄16" x ½"
17 GR2077 1 Hub Cap Gasket
18 GR2078 1 Hub Cap
19 GR2076 1 Cotter Pin, 5⁄16" x 4"
20 GR2072 1 Bearing Cone
21 GR2074 1 Washer, 4" x 21⁄16" x ¼"
22 GR2075 1 Spindle Nut, 2½"
23 GA16871
GR2067
GR2068
GR2069
GR2070 1
-
-
-
-
Hub W/Cups, Grease Fitting, and Stud Bolts (10 Bolt)
Bearing Cup
Bearing Cup
Stud Bolt, ¾"-16 x 2¾"
Self Tapping Grease Fitting, ⅛"-27
24 GR2071 1 Bearing Cone
25 GR2073 1 Grease Seal
26 GD24448 1 Spindle
* Specific brand requests will be supplied only as available from current Kinze Repair Parts stock. If a specific brand
requested is not in stock, the brand available will be supplied.
Model 3700 M0233-02
Rev. 6/14 P134
