Kinze 3000 Rigid Frame Planter Rev. 5/14 - Manual (Page 9)

Gauge Wheels
ITEM PART NO. QTY.
(Per Row)
DESCRIPTION
1 GA10157 - See “Shank Assembly, Seed Tube, and Depth Adjustment” on page P1
2 GA7975
GA7976
1
1
Wheel Arm W/Grease Fitting, Bushings, and Seals, L.H. (Shown) (Includes Items 3
and 13)
Wheel Arm W/Grease Fitting, Bushings, and Seals, R.H. (Includes Items 3 and 13)
3 GB0276 2 Bushing, 1" I.D. x 1¼" O.D. x 1" Long (Per Arm)
4 G10014
G10228
G10216 1
2
2 Hex Head Cap Screw, ½"-13 x 1"
Lock Washer, ½"
Washer, ½" USS
5 GD11423 4 Half Wheel
6 GD1086 2 Tire
7 GD11453 2 Cover
8 G10924
G10620 8
8 Carriage Bolt, 5∕16"-18 x 1¾"
Serrated Flange Nut, 5∕16"-18
9 G10338
G10620 12
12 Carriage Bolt, 5∕16"-18 x 1¼"
Serrated Flange Nut, 5∕16"-18
10 G10010 2 Hex Head Cap Screw, ⅝"-11 x 3"
11 G10018
G10109 14
14 Hex Head Cap Screw, 5∕16"-18 x ⅝"
Lock Nut, 5∕16"-18, Grade 8
12 GA6171 2 Bearing
13 GD10991 2 Seal (Per Arm)
14 G10204 2 Special Machine Bushing, ⅝" x 1" O.D.
15 G10640 1 Grease Fitting, ¼"-28 (Per Arm)
16 G10940 - Machine Bushing, 1" (.048" Thick)
A GA7949 - Gauge Wheel Complete (Items 5-9 and 11-12)
B G1K296 - Gauge Wheel Arm Bushing and Seal Driver Kit, Includes: (1) Seal Driver,
(1) Bushing Driver, (1) Instruction
TM
Model 3000 M0188-02
Rev. 6/11 P6
