Kinze 3000 Rigid Frame Planter Rev. 5/14 - Manual (Page 81)

Hydraulic System, 6 Row 36"/38" and 8 Row 30"
Two-Fold Low Profile Row Marker
ITEM PART NO. QTY. DESCRIPTION
1 --- - See “Master Lift Cylinder” on page P67
2 G10215 2 Machine Bushing, ¾", 14 Gauge
3 G6400-08
GR1037 8
-
Connector W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
4 *A1020
*A1018 2
-
Hose Assembly, ⅜" x 48", 6 Row 36"/38"
Hose Assembly, ⅜" x 40", 8 Row 30"
5 *A3132
*A1054 1
-
Hose Assembly, ⅜" x 178", 6 Row 36"/38"
Hose Assembly, ⅜" x 204", 8 Row 30"
6 --- - See “Lift Assist Cylinder, 6 Row 30"/36"/38" and 8 Row 30"” on page P68
7 *A1000 2 Hose Assembly, ⅜" x 15"
8 *A1019
*A1055 2
-
Hose Assembly, ⅜" x 44", 6 Row 36"/38"
Hose Assembly, ⅜" x 66", 8 Row 30"
9 G2603-08 2 Tee, ¾"-16 Male JIC
10 *A1044
*A1021 1
-
Hose Assembly, ⅜" x 34", 6 Row 36"/38"
Hose Assembly, ⅜" x 56", 8 Row 30"
11 *A3128
*A1039 1
-
Hose Assembly, ⅜" x 52", 6 Row 36"/38"
Hose Assembly, ⅜" x 76", 8 Row 30"
12 --- - See “Slave Lift Cylinder” on page P67
13 --- - See “Row Marker Cylinder, 6 Row 36"/38" and 8 Row 30"” on page P69
14 G6801-08
GR1037 2
-
Elbow W/O-Ring, 90°, ¾"-16 Male JIC To O-Ring
O-Ring
15 G2703-08 2 Bulkhead Tee, ¾"-16 Male JIC
16 G306-08 2 Lock Nut, ¾"-16
17 *A1076 2 Hose Assembly, ⅜" x 30"
18 *A3135 2 Hose Assembly, ⅜" x 100"
19 G6500-08 2 Swivel Elbow, 90°, ¾"-16 Male JIC To Female
20 *A1079 2 Hose Assembly, ⅜" x 24"
21 G6502-08 2 Swivel Elbow, 45°, ¾"-16 Male JIC To Female
22 G6400-08-06
GR1045 2
-
Connector W/O-Ring, ¾"-16 Male JIC To 9∕16"-18 O-Ring
O-Ring
23 --- - See "Row Marker Sequencing/Flow Control Valve" on page P71
24 G6500-08-06 2 Swivel Elbow, 90°, ¾"-16 Male JIC To 9∕16"-18 Female
25 G6400-08
GR1037
G6400-08-04
GR1465 2
-
-
-
Connector W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
Connector W/O-Ring, ¾"-16 Male JIC To 7∕16"-20 O-Ring
O-Ring
26 *A1076 1 Hose Assembly, ⅜" x 30", W/Interplant Package
27 *A3208
*A3209 1
1 Hose Assembly, ⅜" x 140", W/Interplant Package, 6 Row 36"/38"
Hose Assembly, ⅜" x 170", W/Interplant Package, 8 Row 30"
28 *A1013
*A1090 2
-
Hose Assembly, ⅜" x 150", 6 Row 36"/38"
Hose Assembly, ⅜" x 162", 8 Row 30"
29 *A3137
*A3114 2
-
Hose Assembly, ⅜" x 140", 6 Row 36"/38"
Hose Assembly, ⅜" x 156", 8 Row 30"
30 *A3142
*A3147 -
- Hose Assembly, ⅜" x 30", W/Double Frame Package
Hose Assembly, ⅜" x 24", W/Hitch Extensions
31 *A3143 2 Hose Assembly, ⅜" x 100"
32 G2403-08 - Union, ¾"-16 Male JIC
33 --- - See "Interplant Lift Cylinder" on page P70
34 G6602-08 1 Swivel Tee, ¾"-16 JIC
35 *A3150 2-4 Hose Assembly, ⅜" x 56", W/Interplant Package
36 *A3142 1 Hose Assembly, ⅜" x 30", W/Interplant Package (Double Frame Only)
* Hydraulic hose is not stocked by Kinze Repair Parts, but can be made available on a special order basis. Call for quote.
TM
Model 3000 M0188-02
Rev. 6/11 P78
